SCWM-200 external garden grinding and polishing machine
The SCWM-200 external grinding and polishing machine is essential equipment for preparing standard samples for mechanical testing of various rock and mineral stones, concrete, and other non-metallic solids. This machine works in conjunction with our company's core drilling machine to process high-precision cylindrical test specimens with an external circular surface. It is widely used in universities, water conservancy and hydropower, geology and mineral resources, transportation, and construction sectors. The entire machine is easy to operate, with manual or automatic feed, and stable performance. II. Main Technical Indicators 1. Rotary motor power: Y80-2 0.75KW 2800 rpm 2. Grinding wheel motor power: 1.1KW 2800 rpm 3. Workbench motor power: Y80-4 0.55KW 1390 rpm 4. Grinding wheel diameter: 200mm x 19mm x 40mm 5. Specimen specifications that can be ground: Cylinder: 50～150mm 6. Grinding feed: Manual control 7. Cooling device: Connected to tap water for cooling, water flow controlled by a water valve. 9. External dimensions: Length 1390, width 1235, height 1020 mm 10. Weight: 600kg
Keywords:
Detailed description
The SCWM-200 external grinding and polishing machine is essential equipment for preparing standard samples for mechanical testing of various rock and mineral stones, concrete, and other non-metallic solids. This machine works with our company's core drilling machine to process high-precision cylindrical test specimens with external circular surfaces. It is widely used in colleges and universities, water conservancy and hydropower, geological and mineral resources, transportation, and construction sectors. The entire machine is easy to operate, with manual or automatic feed, and stable performance.
II. Main Technical Specifications
1. Rotating motor power: Y80-2 0.75KW 2800 rpm
2. Grinding wheel motor power: 1.1KW 2800 rpm
3. Worktable motor power: Y80-4 0.55KW 1390 rpm
4. Grinding wheel diameter: 200mm x 19mm x 40mm
5. Specifications of samples that can be ground: Cylinder: 50～150mm
6. Grinding feed: Manual control
7. Cooling device: Connected to tap water for cooling, water flow controlled by a water valve.
9. External dimensions: Length 1390 x Width 1235 x Height 1020 mm
10. Weight: 600kg
