SCQ-B-II Automatic Stone Cutting Machine (Blade Splitting Axis Design)

This machine adopts a new inverter motor to control the cutting system. It has the advantages of full sealing, low noise, automatic cutting and adjustable cutting speed, fast forward, automatic backward and so on. This machine can use high-quality stainless steel materials for the shell according to customer requirements, which is durable and beautiful. Using high-grade diamond blade, it can cut two parallel planes at the same time, and the distance between the two planes can be adjusted arbitrarily within the range of 150mm, and special specifications can be made according to requirements. It is suitable for cutting and preparing standard samples in geotechnical laboratories such as highways, railways, construction projects, water conservancy, and schools. This product strictly implements the industry standard of "Highway Engineering Rock Test Regulations" (JTG E41-2005).

Retail price

0.0

元

Market price

0.0

元

Number of views:

1000

Product serial number

Quantity

Stock:

Category

Back



Equipment Parameter

Product description

Parameters

Technical Parameters:

serial number	Specifications series	SCQ-1B型	SCQ-4B型
1	Maximum cut-through height (mm)	Ø170 170mm	Ø220 220mm
2	Diamond cutter (mm)	Ø485	Ø585
3	Form of work	Single and double knives cut two planes, and the distance between the two planes can be adjusted arbitrarily within the range of 150mm	Single and double knives cut two planes, and the distance between the two planes can be adjusted arbitrarily within the range of 150mm
4	Main engine power and speed	Y802-44KW1390 rpm	Y802-44KW1390 rpm
5	Cutter linear speed	0--50m/min (adjustable)	0--50m/min (adjustable)
6	Inverter motors	0.55KW	0.55KW
7	Feed speed	Inverter motors	Inverter motors
8	Panel controls	Button (where the digital display program has been set)	Button (where the digital display program has been set)
9	working hours	coiled	coiled
10	Ambient temperature	0-40℃	0-40℃
11	noises	〈80db	〈80db
12	volume	It is 1580 × long, 1030 × 1300 mm high	It is 1580 × long, 1030 × 1300 mm high
13	quality	750kg	750kg

Cutting table size: table length: 500mm width: 400mm internal width: 550mm

Technical Advantages:

1. Diamond saw blade: The saw blade is made of high-level steel, which is polished after heat treatment and processing, and is not deformed. The diamond cutter head is different from the ordinary saw blade bit, using high-quality A-grade diamond bit, wear resistance, suitable for all kinds of rocks

2. Main engine power: 4KW; Variable frequency motor power: 0.55KW

3. The diameter of the cutting spindle: 55mm, which enhances the stability of the cutting system and the parallelism of the cutting and forming samples

4. Cutting and walking form: the saw blade is fixed, and the workbench specimen is in the form of walking, which changes the status quo of slow speed in the idling walking process of similar products on the market, and the machine adopts a new frequency conversion motor control, which can freely set the walking speed according to the actual operation, reduce the idle walking time and improve work efficiency.

5. The user-friendly design of this machine, fully sealed, we use a slope residue cleaning port under the workbench, so that the cut residue slides directly from this channel, and there will be no stuck track phenomenon and easy to clean.

6. The design of two blades is divided into shafts and strokes, which changes the complex procedure of adjusting the blade spacing before removing the previous saw blade and then reassembling the spacer sleeve, and the blade spacing can be changed directly through the hand-cranked handwheel.
