SCL-1 Rock Collapse Resistance Tester
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
Product description
Parameters
Product Description: This testing instrument is digital display, manually rotating the screw to apply pressure, suitable for expansion pressure tests under constant volume conditions in various rock expansion tests. It is equipped with testing devices such as permeable plates and micrometers.
Technical parameters:
1. Beam thickness: 50-60mm, ensuring the stability of the beam
2. Test force: can be selected between 40-100KN
3. Accuracy: better than level 1
4. Compressed space: 170mm
5. Column spacing: 165 mm
6. Fiberglass ring diameter: 141mm
7. Glass rigid ring height: 66mm
8. Metal ring diameter: 50mm
9. Metal ring height: 55mm
10. External dimensions of the host: 320mm × 320mm × 500mm
Technical advantages:
1. To reduce the gap between the upper connector, the displacement measurement plate is welded together with the upper ball socket to form a whole, reducing the gap.
2. The accuracy of the dial gauge is relatively high. To ensure the effectiveness of displacement, the dial gauge support is fixed at the swing column of the expansion pressure gauge through a nut to ensure stability. The support can automatically lift and rotate, ensuring that the water tank can be freely taken and placed, and the pressurization system can automatically lift and lower.
