SCMP-I Automatic Precision Grinding and Polishing Machine

The SMJ-III automatic precision grinding and polishing machine is a new generation product specifically designed for processing and preparing crystals, ceramics, glass, metals, rock samples, ore samples, refractory materials, PCBs, and composite materials. It is equipped with a 203mm diameter grinding and polishing disc and two processing stations, and can be used for grinding and polishing flat surfaces with a diameter ≤80mm or rectangular shapes. By using this machine and selecting appropriate accessories, high-quality flat grinding and polishing products can be automatically mass-produced. Stepless adjustment of the swing frequency achieves a smoother flat grinding and polishing. Main features: 1. Ultra-flat polishing disc (flatness is less than 0.0025mm per 25×25mm) 2. Ultra

Keywords:

Category:

Grinding machine series

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

The SMJ-III Automatic Precision Grinding and Polishing Machine is a new generation product specifically designed for processing and preparing crystals, ceramics, glass, metals, rock samples, ore samples, refractory materials, PCBs, and composite materials. It is equipped with a 203mm diameter grinding and polishing disc and two processing stations, and can be used for grinding and polishing flat surfaces with a diameter ≤80mm or rectangular shapes. By using this machine and selecting appropriate accessories, high-quality flat grinding and polishing products can be automatically mass-produced. Stepless adjustment of the swing frequency achieves a smoother flat grinding and polishing.

Main Features:

1. Ultra-flat polishing disc (flatness is less than 0.0025mm per 25×25mm)

2. Ultra-precise rotating shaft (turntable end jump less than 0.010mm)

3. Two processing stations

4. Stepless speed regulation with digital display

5. Timer for automatic work stop

6. Can be equipped with a dripper or circulation pump for automatic liquid feeding

Technical Parameters:

1. Grinding disc speed: 0—125 (250) rpm

2. Work stations: 2

3. Number of turntable swings: 0-9 times/min

4. Grinding disc diameter: 203mm

5. Turntable diameter: 80mm

6. AC power supply: 110/220V, power: 300W

7. Turntable end jump: 0.02/100mm, timer: 0-99.99H

8. Stepless speed regulation, robotic arm can swing

Product Specifications:

Dimensions: 580×420×350mm Weight: 68kg
