SCY-2 type rock lateral constraint expansion meter
This testing instrument features a digital dial indicator structure, suitable for axial displacement change tests under lateral constraint in various rock expansion tests. It is equipped with a permeable plate and dial indicator, etc. Technical parameters: 1. Dial indicator range: 5mm 2. Accuracy: 0.001mm 3. Glass tank length * width: 95mm 4. Glass tank height: 85mm 5. Metal ring diameter: φ50mm 6. Metal ring height: 55mm 7. Design specimen size: φ50*20mm 8. Main unit dimensions: 200mm × 100mm × 195mm Note: This product strictly implements the "Highway Engineering... "
Keywords:
Category:
Detailed description
This testing instrument features a digital dial indicator structure, suitable for axial displacement change tests under lateral constraint in various rock expansion tests. It is equipped with a permeable plate and dial indicator, among other testing devices.
Technical Parameters:
1. Dial indicator range: 5mm
2. Accuracy: 0.001mm
3. Glass tank length * width: 95mm
4. Glass tank height: 85mm
5. Metal ring diameter: φ50mm
6. Metal ring height: 55mm
7. Designed specimen size: φ50*20mm
8. Main unit dimensions: 200mm×100mm×195mm
Note: This product strictly adheres to the industry standard of the "Highway Engineering Rock Test Regulations" (JTG E41-2005).
