SCY-1 Rock Swelling Pressure Tester
Product Description: This testing instrument features a digital display and uses a manually rotated screw to apply pressure. It is suitable for volume-constant expansion pressure tests on various rocks. It is equipped with a water permeable plate, a dial indicator, and other testing devices. Technical Parameters: 1. Crossbeam thickness: 50-60mm, ensuring crossbeam stability 2. Maximum test force: Selectable between 40-100KN 3. Accuracy: Better than Class 1 4. Compression space: 170mm 5. Distance between uprights: 165mm 6. Fiberglass ring diameter: 141mm 7. Fiberglass ring height: 66mm 8. Metal ring diameter: 50mm 9. Metal ring height: 55mm 10. Main unit external dimensions: 320mm×320mm×500mm Technical Advantages: 1. To reduce gaps in the upper connecting parts, the displacement measuring plate and the upper ball seat are welded together to form an integral unit, reducing gaps. 2. The dial indicator has high accuracy. To ensure the effectiveness of displacement measurement, the dial indicator support is fixed to the expansion pressure gauge column via a nut to ensure stability. The support can be automatically raised, lowered, and rotated, allowing for easy placement and removal of the water tank, and the pressurization system can be automatically raised and lowered.
Keywords:
Detailed description
Product Description: This testing instrument features a digital display and a manually rotated lead screw for applying pressure. It is suitable for expansion pressure tests under constant volume conditions in various rock expansion tests, and is equipped with permeable plates, dial gauges, and other testing devices.
Technical Parameters:
1. Beam thickness: 50-60mm, ensuring the stability of the beam
2. Maximum test force: 40-100KN selectable
3. Accuracy: Better than Class 1
4. Compression space: 170mm
5. Column spacing: 165 mm
6. Fiberglass ring diameter: 141mm
7. Fiberglass ring height: 66mm
8. Metal ring diameter: 50mm
9. Metal ring height: 55mm
10. Main unit dimensions: 320mm×320mm×500mm
Technical Advantages:
1. To reduce gaps in the upper connectors, the displacement measurement plate and the upper spherical seat are welded together to form an integrated unit, reducing gaps.
2. The dial gauge has high precision. To ensure effective displacement measurement, the dial gauge support is fixed to the pendulum column of the expansion pressure meter with nuts to ensure stability. The support can automatically raise/lower and rotate, ensuring the water trough can be easily removed and replaced, and the pressurizing system can automatically raise/lower.
