SC-55 Type Free Swell Meter
The rock free expansion testing instrument is suitable for determining the expansion properties of rocks containing easily water-absorbing and expanding minerals in their natural state, such as clay rocks. This test is the ratio of the radial and axial deformation produced by the specimen after water immersion to the diameter and height of the specimen, expressed as a percentage. It conforms to the following standards: GBT50266-2013 Standard for Engineering Rock Mass Test Methods; JTGE41-2005 Highway Engineering Rock Test Regulations; SL264-2001 Water Conservancy and Hydropower Engineering Rock Test Regulations; DLT5368-2007 Water Conservancy and Hydropower Engineering Rock Test Regulations; TB10115-2014 Railway Engineering Rock Test Regulations. Main technical parameters: 1. Dial gauge range: 0-3mm Accuracy 0.001mm 2. Water tank: 160×160×130mm 3. Specimen specifications: Cylinder φ50～60mm, height approximately equal to diameter Cube side length 50～60mm, both ends should be parallel and polished 4. External dimensions: 500×500×150mm 5. Weight: 50Kg According to different user needs, an automatic data acquisition system can be selected. This acquisition system uses digital analog sensing, and the computer software automatically acquires test data, saving manpower and increasing the accuracy of test data. This automatic data acquisition system mainly consists of a multi-channel acquisition instrument, computer data acquisition software, and displacement sensors. System main technical parameters (1) Displacement sensor range: 0-10mm; accuracy 0.001mm 5 (2) Multi-channel acquisition instrument, computer data acquisition software functions Real-time acquisition, monitoring, and displacement deformation, and curve graphs; Multiple channels can acquire displacement; Test data can be freely exported for data analysis; Test time can be arbitrarily preset, and the test will automatically stop when the time is up; Sampling time interval can be arbitrarily set Voltage: 220V; Frequency: 50Hz
Keywords:
Category:
Detailed description
The rock free expansion testing instrument is suitable for determining the expansion properties of rocks containing easily water-absorbing and expanding minerals in their natural state, such as clay rocks. This test is the ratio of the radial and axial deformation produced by the specimen after water immersion to the diameter and height of the specimen, expressed as a percentage.
Compliant Standards:
GBT 50266-2013 Standard for Engineering Rock Mass Test Methods;
JTG E41-2005 Highway Engineering Rock Test Procedures;
SL 264-2001 Water Conservancy and Hydropower Engineering Rock Test Procedures;
DLT 5368-2007 Water Conservancy and Hydropower Engineering Rock Test Procedures;
TB 10115-2014 Railway Engineering Rock Test Procedures.
Main Technical Parameters
1. Dial gauge range: 0-3mm Accuracy 0.001mm
2. Water tank: 160×160×130mm
3. Specimen specifications: Cylinder φ50～60mm, height approximately equal to diameter
Cube side length 50～60mm, both ends should be parallel and polished
4. External dimensions: 500×500×150mm
5. Weight: 50Kg
According to different user needs, an automatic data acquisition system can be selected. This acquisition system uses digital analog sensing, and the computer software automatically acquires test data, saving manpower and increasing the accuracy of test data. This automatic data acquisition system mainly consists of a multi-channel acquisition instrument, computer data acquisition software, and displacement sensors.
System Main Technical Parameters
(1) Displacement sensor range: 0-10mm; accuracy 0.001mm 5
(2) Multi-channel acquisition instrument, computer data acquisition software functions
Real-time acquisition, monitoring, and displacement deformation, and curve graphs;
Multi-channel displacement acquisition can be realized;
Test data can be freely exported for data analysis;
The test time can be arbitrarily preset, and the test will automatically stop when the time is up;
Sampling time interval can be arbitrarily set
Voltage: 220V; Frequency: 50Hz
