SCL-1 type rock disintegration tester
Product Description: This testing instrument features a digital display, with manual screw rotation for applying pressure, suitable for expansion pressure tests under constant volume conditions in various rock expansibility tests, and is equipped with permeable plates, dial gauges, and other testing devices.
Keywords:
Category:
Detailed description
Product Description: This testing instrument features a digital display and uses a manually rotated screw to apply pressure. It is suitable for expansion pressure tests under constant volume conditions in various rock expansion tests and is equipped with a water permeable plate, dial indicator, and other testing devices.
Technical Parameters:
1. Crossbeam Thickness: 50-60mm, ensuring crossbeam stability
2. Test Force: Selectable between 40-100KN
3. Accuracy: Better than Class 1
4. Compression Space: 170mm
5. Distance between Columns: 165mm
6. Fiberglass Ring Diameter: 141mm
7. Fiberglass Ring Height: 66mm
8. Metal Ring Diameter: 50mm
9. Metal Ring Height: 55mm
10. Main Unit Dimensions: 320mm×320mm×500mm
Technical Advantages:
1. To reduce gaps in the upper connecting components, the displacement measuring plate and the upper ball seat are welded together to form an integral unit, reducing gaps.
2. The dial indicator has high accuracy. To ensure the effectiveness of displacement measurement, the dial indicator support is fixed to the expansion pressure gauge column via a nut to ensure stability. The support can be automatically raised, lowered, and rotated, allowing for easy placement and removal of the water tank, and the pressurization system can be automatically raised and lowered.
