SC-50A liquid nitrogen freezing drilling machine
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
Product description
Parameters
First, the function:
It can also be used for the drilling of ordinary non-loose rock samples.
Second, the main specifications:
Drilling core specifications: Ф25 × 25mm, Ф38 × 25mm, Ф50 × 50mm and so on
Diamond drill specifications: Ф50mm
Power: 2.2KW
Drilling speed: 2840r / min
Power supply: 380V
Third, the technical characteristics:
Spindle made of stainless steel or hard chrome plating, to avoid prolonged soaking lead to rust, rotation is not flexible, affecting the normal operation.
Fourth, before the core preparation:
1, will be connected to the cooling jacket interface with the cooling source is connected to the cooling source can be a liquid nitrogen tank, tap water or other.
2, exhaust fan exhaust pipe connected to the outdoors, to prevent indoor nitrogen concentration is too large.
3, connected to the 380V AC power supply.
4, to ensure a reliable grounding equipment.
Fifth, the operation:
1, the frozen rock samples taken over the clamp and clamping.
2, open the nitrogen bottle pressure liquid nitrogen (tap water) to drill.
4, turn on the power switch, drill rotation, exhaust fan to work.
5, press the handle, so that the core began to feed the core sampling.
6, core-like drilling is completed, release the handle so that the drill out of the core fixture, power off, nitrogen bottle.
7, re-sampling Repeat the above action, turn on the power switch, nitrogen bottle, feed rock samples.
8, drilling is completed, the drill core out of the fixture, power off, nitrogen bottles, remove the drilling of the core.
9, with water or other liquid to do coolant, the waste liquid from the liquid tray under the discharge port with a hose discharge. Clean up when used to prevent corrosion.
