SC300A Programmed Drilling Sampler
This new core sampler is essential equipment for laboratory sampling. It features a double-column structure, stable performance, beautiful appearance, durability, high strength, low noise, and easy operation. It is widely used in laboratories in the petroleum, geological, coal, metallurgical, construction, and transportation sectors. Main technical parameters: 1. Diamond drill bit: JR3# drill bit 2. Maximum sampling diameter: Φ200mm 3. Drilling stroke: 400mm 4. Equipped with PLC, display screen 5. Main motor power: 4KW 6. Spindle speed: 1400 rpm 7. Lifting motor: 0.55KW, frequency conversion speed regulation motor 8
Keywords:
Detailed description
This new core sampler is essential equipment for laboratory sampling. It adopts a double-column structure, ensuring stable performance. Its advantages include beautiful appearance, durability, high strength, low noise, and ease of operation. It is widely used in laboratories of petroleum, geological, coal, metallurgical, construction, and transportation sectors.
Main Technical Parameters:
1. Diamond Drill Bit: JR3# drill bit
2. Maximum Sampling Diameter: Φ200mm
3. Drilling Stroke: 400mm.
4. Equipped with PLC and display screen
5. Main Motor Power: 4KW
6. Main Spindle Speed: 1400 rpm
7. Lifting Motor: 0.55KW, frequency conversion speed regulation motor
8. Drilling Method: Automatic loading, frequency conversion speed regulation
9. Automatic Drilling Speed: Stepless speed regulation
10. Equipped with an automatic lubrication bronze bushing inlaid with graphite and MoS2 solid lubricant
11. The double column adopts high-precision chrome-plated high-frequency quenching linear optical axis
12. Equipped with a worktable that can move left and right, and forward and backward
13. Equipped with a ball screw and stepper motor
14. Equipped with an electronic handwheel to adjust the drilling position (electronic handwheel and automatic worktable control are optional)
15. Equipped with an overload circuit automatic protection system
16. The control box can rotate left and right and is equipped with an automatic positioning device
17. Automatic control system for tap water cooling
18. Equipped with an automatic lubrication system
19. Working Time: Continuous
20. Optional installation of an electromagnetic chuck
