SC300 automatic coring machine

Product Description: This machine uses a double-column support to obtain more complete and accurate core samples. The drilling speed is controlled by a frequency converter, which overcomes the drawbacks of the previous DC180 motor, which was slow and only adjustable to three speeds, and required carbon brush replacement at intervals. This machine is easy to operate; simply press the up and down buttons for automatic vertical movement. When taking a core sample, simply press the main button and select the desired speed for automatic coring. This machine can use a variety of cooling methods, including water cooling, liquid nitrogen cooling, and a dust removal system for dry cutting. An electromagnetic chuck can be selected for the worktable. Technical parameters:

Keywords:

Category:

Concrete, core drilling machine

Phone:

Detailed description

Product Description:

This machine uses a double-column support, making the obtained core samples more complete and accurate. The drilling speed uses a variable frequency drive, which changes the slow speed and only three adjustable speed levels brought by the previous DC180 motor, and the disadvantage of having to change carbon brushes every period of time. This machine is easy to operate; simply press the up and down buttons to automatically move up and down. When taking a core sample, simply press the main unit button and select the required speed to automatically take the core sample. This machine can use a variety of cooling methods, such as water cooling, liquid nitrogen cooling, and a dust removal system can be added for dry cutting. The worktable can use an electromagnetic chuck.

Technical Parameters:

1. Diamond drill bit: JR360 (special rock core diamond drill bit)

2. Core diameter: φ20--φ200mm

3. Maximum drilling depth: 400mm

4. Main motor power: 3KW

5. Variable frequency motor power: 0.55KW

6. Drilling speed: 0--50m/min (adjustable according to the hardness of the rock sample)

7. Working time: Continuous

8. Fixture: Electromagnetic chuck type, freely combinable. The workpiece clamping of the worktable can be adjusted arbitrarily in the longitudinal and transverse directions

9. Working method: Automatic drilling and sampling, the drill bit automatically returns to the starting position after sampling;

10. Cooling method: Tap water cooling, liquid nitrogen cooling or dry cutting dust removal

11. Dimensions: Length × Width × Height = 1200 × 750 × 1600mm

Weight: 600kg
