SCM200 Program-controlled type

Product Description: The SCM200 CNC double-sided grinder is a new generation of automatic CNC grinder newly developed by our factory. It is essential equipment for making standard samples for mechanical testing of various non-metallic solids such as rocks, minerals, and concrete. This machine adopts an advanced measurement system. User-friendly tablet computer input, full monitoring of the grinding process, automatic compensation system for grinding wheel wear, making sample grinding simpler. Enter the sample size on the display screen, and the system will start working and return after reaching the set size. This machine consists of a machine base, a grinding power head stepping motor system, electrical and control devices, compensation coefficients, and a measurement system.

Keywords:

Category:

Grinding machine series

Concrete, core grinder

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

Product Description:

The SCM200 CNC double-sided grinder is a new generation of automatic CNC grinder newly developed by our factory. It is essential equipment for making standard samples for mechanical testing of various non-metallic solids such as rocks, minerals, and concrete. The machine uses a measurement system. User-friendly tablet computer input, full monitoring of the grinding process, and automatic compensation system for wheel wear make sample grinding simpler. Enter the sample size on the display screen, and the system will start working and return after reaching the set size. This machine consists of a machine base, a grinding power head stepping motor system, electrical and control devices, a compensation coefficient, and a measurement system. One-button operation, automatic completion.

Technical Parameters:

1. Workbench motor power: 0.55KW Speed 720rpm

2. Grinding power head power: 1.1KW × 2 units Speed 2750rpm

3. Servo motor

4. Measurement system

5. System digital circuit

6. Panel control: Touch screen

7. Electrical control: PLC, digital circuit, automatic interpolation adjustment for wheel wear.

8. Grinding wheel diameter: 200mm

9. Sample specifications that can be ground: (Normal factory configuration grinds 50~150mm fixtures)

a: Cube: 50×50×50~150×150×150mm

b: Cylinder: 50~150mm

10. Automatic grinding feed: Input on the display screen.

11. Cooling device: Tap water cooling.

The above products can be produced with all stainless steel materials according to customer requirements. In case of discrepancy between the actual product and the picture, the actual product shall prevail!
