SCQM-200 automatic cutting and grinding machine

The SCQM-200 integrated rock cutting and grinding machine is a new type of sample preparation equipment recently developed by our factory. It uses electrical control. The machine consists of a base, a workbench, a grinding power head, a cutting system, and other series of devices. The whole machine is easy to operate, with button controls on the console. Its performance is completely stable. It is widely used in colleges and universities, water conservancy and hydropower, geology and mineral resources, transportation, construction, and other departments. It is the most ideal equipment for preparing thin sections in laboratories.

Keywords:

Geotechnical sampling equipment series

Category:

Multi-purpose slicing, grinding and drilling machine series

Core cutting machine

Geological mineral rock thin section cutting machine

alkali aggregate petrographic method rock column method cutting and polishing machine

Bubble gap coefficient lapping and polishing machine

Material sample cutting machine

Concrete and rock core cutting and grinding integrated machine

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

The SCQM-200 rock cutting and grinding machine is a new type of sample preparation equipment recently developed by our factory. It uses electrical control and consists of a base, worktable, grinding power head, cutting system, and other series of devices. The entire machine is easy to operate with button controls on the control panel. Performance is completely stable. It is widely used in colleges and universities, water conservancy and hydropower, geology and mineral resources, transportation, construction, and other departments. It is the ideal equipment for preparing thin sections in laboratories.

Main Technical Specifications

1. Diamond grinding wheel diameter: Φ125/200mm

2. Diamond blade diameter: Φ200/300mm

3. Total motor power: 1.5KW +1.5KW+0.75kw

6. Sample range that can be cut and ground: ¢9-70mm

7. Cooling medium: Water cooling.

8. External dimensions: 720*720*1170mm

9. Weight: 158Kg
