SCQ300A Programmed Rock Slicer

Keywords:

Category:

Thin Slicer Series

alkali aggregate petrographic method rock column method cutting and polishing machine

Bubble gap coefficient lapping and polishing machine

Geological mineral rock thin section cutting machine

Material sample cutting machine

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

The SCQ-300A is our factory's new type of cutting machine. This cutting machine is suitable for cutting ceramics, glass, rock samples, ore samples, concrete, and silicon crystals. Equipped with a high-precision walking system, it offers accurate cutting and is an effective tool for material analysis. The machine is controlled by programming software, with precisely adjustable data, and is equipped with a high-performance Delta PLC and touch screen. The X and Y axes are equipped with stepper motors and their drivers.

Main Technical Parameters

1. Spindle speed: 2800rpm

2. Cutting blade size: 300mm

3. Voltage: 220V/380V

4. Total power: 1300W

5. Maximum X-axis travel: 100mm

6. Maximum Y-axis travel: 350mm

7. Maximum cutting sample size: 100*100mm

8. Minimum cutting sample size: 7*1mm

9. Indicated accuracy of diamond blade feed: 0.5mm

10. Data input: Data input on the touch screen.

11. Control: Programming.

12. Dimensions: 920*870*600mm

13. Weight: 185kg
