Rock porosity tester
Keywords:
Category:
Detailed description
Applicable Industries:
Mineral mining industry, geological research laboratories
Product Introduction:
Using internationally recognized high-sensitivity, high-stability gold-plated ceramic sensor technology, it leads the industry in terms of cost performance. Using water as the medium (alcohol optional), only two steps are required to display the density value. No manual calculation is needed, making it more convenient, faster, and time-saving.
Special Features:
● Provides four measurement methods according to national standards: boiling method, vacuum saturated water method, wax sealing method, and solution compensation method
● For closed-pore saturated water rocks, density and volume can be read directly
● Can measure the water absorption rate of rocks
● Using the wax sealing method for rock density testing, the bulk density can be read directly
● Size can be customized according to the size of the rock
Technical Parameters:
| Model: | YSKX-300Z | YSKX-600Z | YSKX-120Z | YSKX-300XZ |
| Weighing Accuracy: | 0.005g | 0.001g | ||
| Maximum Weighing: | 300 | 600 | 120 | 300 |
| Density Resolution: | 0.001g/cm³ | 0.0001g/cm³ | ||
| Measurement Types: | Solid particles | |||
| Measurement Time: | Approximately 10 seconds | |||
| Setting Functions: | Temperature compensation setting, solution compensation setting, four measurement modes selection | |||
| Measurement Functions: | Density, wet density, porosity, water absorption rate, open pore volume | |||
| Windshield: | Fully transparent acrylic windshield, 100% sample visibility | |||
| Communication Interface: | Standard RS232 communication interface, can be connected to printers, PCs, and other peripheral devices | |||
| Voltage: | AC100-240V-50/60HZ DC 7.5V 600mA | |||
| Tank Dimensions: | 165*115*85mm | |||
| Packaging Dimensions: | 450*240*460mm | |||
| Instrument Dimensions: | 270*270*270mm | |||
| Weight: | 7.5kg | |||
| Standard Accessories: | ①Host ②Tank ③Measuring platform ④Tweezers ⑤Manual ⑥Weights ⑦Dust cover ⑧Anti-floating frame ⑨Power supply | |||
| Optional Accessories: | Printer ×1 (ordinary model) Printer ×2 (with time function) Wax furnace (wax sealing) Vacuum pump (vacuuming) | |||
Product Features:
1. Fool-proof operation, fully automatic density measurement
2. Creative and trendy appearance, outstanding overall texture, rigorous and exquisite craftsmanship.
3. Using internationally recognized high-sensitivity, high-stability gold-plated ceramic sensor technology, leading the industry in terms of cost performance.
Features corrosion resistance, long lifespan, and low failure rate.
4. Density accessories designed based on 10 years of experience, suitable for various fields.
5. Uses an integrated transparent measuring tank, corrosion-resistant
Compliance Standards:
According to GB/T1933, ASTM, JIS, ISO standards.
