SC-300A-T Automatic Core Sampler (Programmable Dual Frequency Conversion)

Keywords:

Category:

Concrete, core drilling machine

Core drilling series

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

Product Description:

This machine uses a double-column support plus a double guide column support to obtain more complete and accurate core samples. The drilling speed uses a frequency converter to adjust the speed, changing the previous DC180 motor's slow speed and only three adjustable speed levels, and the disadvantage of having to change carbon brushes every period of time. This machine's operation uses a programmable control type (operated directly on the display screen), which is simpler. This machine can use multiple cooling methods, including water cooling, liquid nitrogen cooling, and a dust removal system (optional) can be added during dry cutting. The worktable uses a pneumatic automatic clamping method, making core sample clamping more convenient.

Technical Parameters:

1. Diamond drill bit: JR360 (special rock core diamond drill bit)

2. Core diameter: φ7--φ200mm

3. Maximum drilling depth: 400mm

4. Main motor power: 3KW

5. Variable frequency motor power: 0.55KW

6. Drilling speed: 0--50HZ (adjustable frequency according to the hardness of the rock sample)

7. Drill bit rotation speed: 0--50HZ (adjustable frequency according to the hardness of the rock sample)

8. Working time: Continuous

9. Operation control: Direct operation on the display screen (frequency converter + PLC + electrical components + display screen, etc.)

10. Fixture: Uses pneumatic clamping, convenient and fast. Crisscross chassis

11. Workspace: Extra-large effective workspace: 650*400*400mm

12. Working method: Automatic drilling and sampling, the drill bit automatically returns to the starting position after sampling;

13. Cooling method: Tap water cooling, liquid nitrogen cooling or dry cutting dust removal

14. Dimensions: Length × Width × Height = 1200 × 750 × 1600mm

15. Weight: 560kg
