SCM-200E-T type program-controlled core automatic grinding system
Keywords:
Category:
Detailed description
I. Overview
The SCM-200E-T type programmable core automatic grinding system is a new type of partial surface grinding equipment newly developed by our factory. It adopts programmable control and consists of a base, workbench, grinding power head, variable speed transmission system, stepping motor, programmable digital display control screen, PLC and other series of devices. The whole machine is easy to operate, all program actions can be operated on the digital display control screen, and can also be operated by buttons on the control panel. The performance is completely stable. It is widely used to provide comprehensive scientific research and experimental solutions for customers in the fields of energy exploration and development, geotechnical engineering, chemical industry, and scientific education. It is an ideal equipment for preparing thin sections in laboratories for colleges and universities, water conservancy and hydropower, geological and mineral resources, transportation, and construction departments.
II. Main Technical Indicators
1. Fixture: "V" shaped design, suitable for semi-circular samples of ￠45-Φ105mm.
2. Grinding feed speed: Adjustable within 0-50HZ variable frequency speed regulation
3. Diamond grinding wheel diameter: Φ200mm
4. Total motor power: 2KW 5. Grinding head motor power: 1.1KW
6. Maximum sample size that can be ground: Φ105mm*1100mm
7. Minimum feed amount: 0.01mm.
8. Programmable controller: PLC and flat touch screen control
9. Data input: Touch tablet computer.
10. Control method: Automatic or manual.
11. Cooling medium: Water cooling.
14. Dimensions: 1860*960*1700mm
15. Weight: 650Kg
