SCM-3P Multi-point Pressure Grinding and Polishing Machine
Keywords:
Category:
Detailed description
Primarily used in the field of materials research. Suitable for automatic grinding and polishing of metal, ceramic, glass, rock, and ore samples, and also applicable for small-scale production in factories. This machine features high processing precision, stable and reliable performance, simple operation, and a wide range of applications. It is widely used in colleges and universities, research institutes, and production fields.
Main Technical Parameters
1. Polishing disc (lower disc) diameter: φ255mm
2. Polishing disc (lower disc) speed: 0-400rpm (incremental speed control, minimum increment 10)
3. Sample loading disc (upper disc) diameter: φ150mm Circular hole diameter: φ20mm (customizable)
4. Gravity sample loading disc diameter: φ80mm Repair ring: φ95mm
5. Polishing head spindle speed: 10-80rpm (stepless speed regulation), recommended range: 10-50rpm
6. Loading range: 0.5-20Kg (minimum increment 0.5Kg), recommended range: 0.5-15Kg
7. Power supply: 220V 50Hz
8. Dimensions: 660 ×460 ×760 mm
9. Weight: 95Kg
