SC200-T Automatic Coring Machine (Pneumatic, Longitudinal and Transverse)

This machine uses a double-column and double-guide column support to obtain more complete and accurate core samples.

Keywords:

Category:

Core drilling series

Concrete, core drilling machine

Phone:

0523-88520868

Related Products

Inquiry Message

Detailed description

Product Description:

This machine uses a double-column and double-guide column support to obtain more complete and accurate core samples. The drilling speed uses a frequency converter to adjust the speed, changing the slow speed and only three adjustable speed levels brought by the previous DC180 motor, and the disadvantage of having to change carbon brushes every period of time. This machine is easy to operate; just press the up and down buttons to automatically move up and down. The program can also be input into the PLC for program control, which is the programmable type (optional). When taking cores, simply press the main machine button and select the required speed to automatically take cores. This machine can use a variety of cooling methods, water cooling, liquid nitrogen cooling, and a dust removal system can be added during dry cutting (optional).

Technical Parameters:

1. Diamond drill bit: JR360 (special rock core diamond drill bit)

2. Core diameter: φ20--φ200mm, hole diameter: >7mm

3. Maximum drilling depth: 400mm

4. Main motor power: 3KW

5. Inverter motor power: 1.1KW

6. Drilling speed: 0--50m/min (adjustable according to the hardness of the rock sample)

7. Working time: Continuous

8. The workpiece clamping of the workbench adopts pneumatic clamping (optional), which can be adjusted in any longitudinal and transverse direction.

9. Working method: Automatic drilling and sampling, the drill bit automatically returns to the starting position after sampling;

10. Cooling method: Tap water cooling, if liquid nitrogen cooling or dry cutting dust removal is required, please book in advance

11. Volume: Length × Width × Height = 1200 × 750 × 1600mm

12. Weight: 380kg
