SCQ-12A vertical three-axis cutting machine

This machine adopts a hand-cranked (push-type) cutting system. It features full sealing, low noise, durable use, and an aesthetically pleasing appearance. It uses premium diamond blades for flat cutting. The saw blade is height-adjustable and includes a dust removal system and a water circulation system. Special specifications can be customized upon request. Suitable for cutting and preparing standard samples in rock and soil laboratories for highway, railway, construction projects, water conservancy, and schools. This product strictly adheres to the industry standard of the "Highway Engineering Rock Test Regulations" (JTG E41-2005).

Keywords:

Category:

Cutter series

Concrete and rock core cutting machine

Jet large plate cutting machine

Asphalt cutting machine

Phone:

Detailed description

This machine adopts a hand-cranked (push-type) cutting control system. It features full sealing, low noise, durable use, and an aesthetically pleasing appearance. Using premium diamond blades, it provides a flat cutting surface. The saw blade is height-adjustable and includes a dust removal system and a water circulation system. Special specifications can be customized upon request. Suitable for cutting and preparing standard samples in geotechnical laboratories for highway, railway, construction projects, water conservancy, and schools. This product strictly adheres to the industry standard of the "Highway Engineering Rock Test Regulations" (JTG E41-2005).

Technical Parameters:

Serial Number	Specifications Series	SCQ-12A Model
1	Maximum Cutting Height (mm)	Ø170 170mm
2	Diamond Cutting Blade (mm)	Ø485*55
3	Working Mode	Hand-pushed or Hand-cranked
4	Main Engine Power and Speed	Y802-4 11KW 1390 rpm
5	Cutting Blade Linear Speed	33-45m/min
6	Lifting Motor	750W
7	Feed Rate	Controllable
8	Worktable	Translatable
9	Panel Control	Button
10	Working Time	Continuous
11	Ambient Temperature	0-40℃
12	Noise	(80db
13	Dimensions	Length 1580 × Width 1100 × Height 1600mm
14	Weight	450kg

Technical Advantages:

1. Diamond Saw Blade: The blade is made of high-manganese steel, processed by heat treatment and polishing, ensuring no deformation. Unlike ordinary saw blades, it uses high-quality Grade A diamond cutting heads, offering superior wear resistance and suitability for various rocks.

2. The saw blade can move vertically and horizontally.

3. Cutting spindle diameter: 55mm, enhancing the stability of the cutting system and improving the parallelism of the cut samples.

4. Cutting travel mode: This machine addresses the slow speed of idling travel in similar products on the market. It adopts a fully manual control system, allowing users to freely adjust the travel speed during operation, reducing idling time and improving work efficiency.

5. This machine has a dust removal system.

6. This machine has an internal water circulation system.

7. The worktable of this machine can move left and right according to the size of the sample.
